<ul> <li> Allows sharing of up to 4 USB 3.2 devices among 8 PCs</li> <li> Bandwidth speed of 5 Gbps and backward compatibility with USB 2.0/1.1 to ensure swift data transmission</li> <li> Versatile port selection methods – front panel pushbutton, RS-232/RS-485 serial commands, and external remote port selector<sup>1</sup></li> <li> Power on Detection<br /> – Automatically switches the PC focus to the last plugged-in/powered-on host device<br /> – Configurable priority port preference – allows the focus to switch to a secondary USB host when the primary one is lost</li> <li> Front panel port status LEDs – indicate which one of the PCs connected to the US3384i is having the focus at a glance</li> <li> Supports USB BC 1.2 to ensure sufficient power for downstream USB devices</li> <li> Overvoltage protection circuit – extends device lifespan and minimizes risks of electrical hazards/explosions led by voltage spikes surpassing safe operating limits</li> <li> Supports DC 9 – 24V power input through terminal block<sup>2</sup></li> <li> Plug-and-play on Windows and macOS operating systems – no drivers are needed</li> <li> Hot-pluggable – users can connect/disconnect the host devices dynamically to the US3384i without powering off the switch</li> <li> Wall-mountable case constructed with premium metal for enhanced durability<br /> <br /> Note:<br /> 1. The remote port selector is sold separately, please contact your ATEN dealer for product information.<br /> 2. Supports either of the following power supplies:<br /> (1) DC terminal block<br /> (2) DC power jack (The power adapter (0AD8-8012-50M2) is sold separately, please contact your ATEN dealer for product information.)</li> </ul> <p> </p> <table align="left" border="1" class="spec_table"> <tbody> <tr> <td class="title"> Computer Connections</td> <td class="value"> 8</td> </tr> <tr> <td class="title" colspan="2"> Connectors</td> </tr> <tr> <td class="subtitle"> Computer</td> <td class="value"> 8 x USB 3.2 Gen 1 Type-B Female (Blue)</td> </tr> <tr> <td class="subtitle"> Device</td> <td class="value"> 4 x USB 3.2 Gen 1 Type-A Female (Blue)</td> </tr> <tr> <td class="subtitle"> Serial</td> <td class="value"> 2 x 3-pin Terminal Block (Green)</td> </tr> <tr> <td class="subtitle"> Power</td> <td class="value"> 1 x 2-pin 9-24V Terminal Block (Green)</td> </tr> <tr> <td class="subtitle"> Power (Optional)</td> <td class="value"> 1 x 12V DC Jack Female (Black)</td> </tr> <tr> <td class="title"> Power Consumption</td> <td class="value"> DC12V:0.52W:130BTU/h<br /> DC24V:0.53W:130BTU/h<br /> <br /> Note:<br /> ● The measurement in Watts indicates the typical power consumption of the device with no external loading.<br /> ● The measurement in BTU/h indicates the power consumption of the device when it is fully loaded.</td> </tr> <tr> <td class="title"> Power Mode</td> <td class="value"> Terminal Block / DC Jack Power Adapter*<br /> <br /> *The power adapter (0AD8-8012-50M2) is sold separately, please contact your ATEN dealer for product information.</td> </tr> <tr> <td class="title"> Port Selection</td> <td class="value"> Pushbutton / Remote Port Selector* / Serial Command<br /> <br /> *The remote port selector (2XRT-0016G-1) is sold separately, please contact your ATEN dealer for product information.</td> </tr> <tr> <td class="title" colspan="2"> LEDs</td> </tr> <tr> <td class="subtitle"> Selected</td> <td class="value"> 8 (Orange)</td> </tr> <tr> <td class="title" colspan="2"> Cable Length</td> </tr> <tr> <td class="subtitle"> USB Cable</td> <td class="value"> 8 x USB 3.2 Gen 1 Type-A to Type-B Cables 1.2m</td> </tr> <tr> <td class="title" colspan="2"> Environmental</td> </tr> <tr> <td class="subtitle"> Humidity</td> <td class="value"> 0-80% RH, Non-condensing</td> </tr> <tr> <td class="subtitle"> Operating Temperature</td> <td class="value"> 0–50°C</td> </tr> <tr> <td class="subtitle"> Storage Temperature</td> <td class="value"> -20–60°C</td> </tr> <tr> <td class="title" colspan="2"> Physical Properties</td> </tr> <tr> <td class="subtitle"> Housing</td> <td class="value"> Metal</td> </tr> <tr> <td class="subtitle"> Weight</td> <td class="value"> 0.50 kg ( 1.1 lb )</td> </tr> <tr> <td class="subtitle"> Dimensions (L x W x H)</td> <td class="value"> 20.00 x 8.06 x 2.50 cm<br /> (7.87 x 3.17 x 0.98 in.)</td> </tr> </tbody> </table> <p> </p> <p> </p>
